• – Chipset: Intel@ H510 Chipset
• – Socket: Intel® Socket 1200
• – Memory: 2 * DDR4 2133/2400/2666/2933/3200
• – LAN: Support Realtek® RTL8111E 1000M
• – Audio: Support Realtek® ALC662 High Definition Audio

Specifications

Brand Ease
Model EM510B

Processor Support

• Intel® Socket 1200 Support Intel® 10th / 11th Core i3/i5/i7/i9, Pentium® Celeron® Processor

Chipset

• Intel@ H510 Chipset

Memory Support

• 2 * DDR4 2133/2400/2666/2933/3200 DIMM Max 64GB

LAN Support

Realtek® RTL8111E 1000M Optional Realtek® RTL8106E 100M
Audio Support

• Realtek® ALC662 High Definition Audio Optional Realtek® RTL897 High Definition Audio

SATA

• 4 * SATA 3.0 Port 1 * M2_SSD(2242/2280) Support PCIe Signal

USB

• 4* USB 3.0 Ports
• 4* USB 2.0 Ports

Back Panel

• 2 x USB 2.0 Ports
• 1 x VGA Port
• 1 x HDMI Port
• 2 x USB3.0 Ports Gen 1
• 2 x USB 2.0 Ports (colay KB_MS)
• 1 x LAN Port
• 1 Audio Port(Line in/ Line Out/ Mic in)

On-Board

• Pinheaders/Connectors 1 x F_USB 3.0 Pinheader
• 1 x F_USB 2.0 Pinheader
• 1 x F_Audio Pin header
• 1 x F_Panel  Pinheader
• 1 x SYS_Fan Pin Header
• 1 x COM Pinheader
• 1 x ME Pin Header
• 1 x CPU_Fan Pin Header
• 1 x 24-Pin ATX Power Connector
• 1 x 8-Pin ATX
• 1 x CLR_CMOS Pinheader
• 1 x ESPI Pinheader

Slots

• 1 x PCI Express x 16 Slot
• 1 x PCI Express x 1 Slot

Form Factor

• Micro-ATX(220mm X 175mm),6 mounting holes

Acessories (Optional)

• 2 X SATA data cable
• 1X I/O Backboard
• 1X User Manual
• 1X Drives intalled CD
